Troptec UC 65 SG NI

FEATURES

• Easy fabrication and fast assembly with butt joints
• High level of weathertightness due to multi-chamber principle and horizontal saddle gasket throughout
• Stack-joint heights of 10 mm or 20 mm possible
• Spandrel units and window insert units can be integrated
• Adjustable unit attachments with horizontal and vertical tolerance equalization
• Proven quality in accordance with system testing and AAMA
• Flexible system with attachment detail solutions (building) and interfaces (insert units and external solar shading)

Parameters	Values
Face width	65mm
Basic depth	160 mm
Maximum Weight	Upto 400Kgs
Specifications	Maximum Field width (mm) Maximum Storey Height (mm) 1500 3900
Glass Thickness	Single Glazing – 6-8mm, Insulating Glass -22-26mm
Wind load resistance	Up to 720 Pa
Water Tightness	Up to 2870 Pa

Parameter	Testing Value	Testing Standard
Air Permeability	600 Pa	ASTM E 283
Static Water Penetration	720 Pa	ASTM E 331
Windload	2873 Pa	ASTM E 330
